Automatic Double Loop Wire Forming Punching and Binding Machine

Tag : double loop wire binding,wire-o binding,exercise book
Automatic Double Loop Wire Forming Punching and Binding Machine is the high efficiency binding equipment for various double loop wire books, notebooks, and table calendars, etc. With the integration of automatically double loop wire forming from the wire materials, the bigger cover and inner paper punching separately, then wire-o loop cutting, binding and end closing for various stationery products, only need 1-2 operators, easy to adjust, high speed and stable.

Parameter

  • Speed
  • 800-1800 books/hour
  • Punching thickness(one-time)
  • 1-6mm
  • Max. punching thickness
  • 13mm(16mm for special product)
  • Max times of punching one book
  • 5 times
  • Max. book size
  • 510mm(punched side)×800mm
  • Min. book size
  • 100mm(punched side)×140mm
  • Max. book size for feeding belt
  • 420×420mm
  • Size of double loop wire
  • 1/4"-5/8"
  • Pitch
  • 2/1; 3/1
  • Width of paper for binding
  • 100-520mm
  • Air pressure
  • 0.7-0.8Mpa
  • Power
  • 220V/ 50-60Hz/ 1PH/ 4.5kw
  • Net weight
  • 2000kg
  • Machine dimension
  • 4800×2600×1600mm
