Transform Book Packaging Efficiency with the Kraft Paper Packing Machine

In the publishing and printing industry, packaging is more than just a protective step—it is a vital part of the supply chain that affects delivery safety, storage efficiency, and customer satisfaction. Manual packaging of book stacks is not only labor‑intensive but also inconsistent in quality, especially when dealing with large volumes. The HXM13 Automatic Book Stack Kraft Paper Packing Machine addresses these challenges by integrating every stage of the packaging process into a single, continuous, and fully automated workflow.

HXM13 Automatic Book Stack Kraft Paper Packing Machine

The machine is engineered to handle book stacks ranging from 64K to 16K formats, with pack lengths from 180mm to 360mm, widths from 140mm to 256mm, and heights from 80mm to 270mm. This flexibility makes it suitable for a wide variety of products, including paperback sets, hardcover collections, educational material bundles, and promotional book kits. With a maximum pack weight capacity of 7.5 kg, it can manage both light and moderately heavy loads without compromising speed or stability.

One of the defining strengths of the HXM13 is its fully automated changeover capability. Switching between different packaging formats takes less than one minute, a critical advantage for facilities handling multiple product lines or frequent size changes. This rapid adaptability minimizes downtime, increases throughput, and allows businesses to respond quickly to shifting market demands.

The HXM13 operates at a maximum speed of 10 packs per minute, delivering consistent performance without sacrificing precision. Its servo‑driven system ensures accurate paper cutting, folding, and sealing, while advanced industrial controls maintain synchronization across all processes. This level of automation not only improves efficiency but also significantly reduces labor costs, as fewer operators are needed to oversee production.

Material compatibility further enhances its versatility. The machine works with kraft paper thicknesses from 60gsm to 120gsm, with a maximum paper width of 550mm and cutting lengths up to 950mm. Tape sealing is supported with widths from 40mm to 60mm, ensuring secure closure for all pack types. These specifications make the HXM13 compatible with standard packaging materials readily available in most markets.

Built for industrial durability, the HXM13 measures 5000×1600×1700mm, operates on a 3‑phase 380V power supply with a 4.5kW rating, and requires compressed air at 0.5–0.7 MPa. Its robust construction and 1500 kg weight ensure stability during high‑speed operation, reducing vibration and maintaining consistent output quality.

For publishers, printers, and logistics operators seeking to modernize their packaging lines, the HXM13 offers a future‑proof investment. It combines speed, precision, and flexibility in a single machine—streamlining operations, lowering costs, and enhancing the professional presentation of every shipment.
